Kit di altoparlanti, 2 vie, 160 watt max, 80 watt nominali, woofer diametro 130 mm con cono in polipropilene placcato color titanio, tweeter orientabile con bobina da 25 mm e magnete al neodimio, filtro crossover 4000 Hz 12/24 dB/oct con protezione elettronica uscita tweeter
TECHNICAL DATA:
nominal impedance (Zn): 4 ohm
max power (Pm): 160 watt
nominal power (Pn): 80 watt
sensitivity (2.83 V/1 m): 90 dB
freq. range (BW): 60÷20000 Hz
woofer data
nominal impedance (Zn): 4 ohm
nominal power (Pn): 80 watt
max power (Pm): 160 watt
frequency range (BW): 60÷6000 Hz
voice coil diameter: 25 mm
cone material: polypropylene
surround material: butyl rubber
basket material: stamped steel
magnet material: ferrite
tweeter data
nominal impedance (Zn): 4 ohm
nominal power (Pn): 100 watt
max power (Pm): 200 watt
frequency range (BW): 3÷20 KHz
voice coil diameter: 25 mm
dome material: silk
magnet material: neodymium
filter data
crossover frequency: 4000 Hz
low-pass slope: 12 db/oct
high-pass slope: 24 dB/oct
electronic power control
size: 65x120x33 mm
