Audison SRx 3.1

Amplificatore 3 canali nuovo, perfetto - provenienza espositore negozio.

OUTPUT POWER (RMS) @ 14.4 VDC, THD 1%:
•3Ch         75Wx2(4 Ω) + 270Wx 1 (4 Ω)
•3Ch        65Wx2 (4 Ω) + 380Wx 1 (2 Ω)
•3Ch         110Wx 2 (2 Ω) + 250Wx 1 (4 Ω)
•3Ch         95Wx2 (2 Ω) + 350W x1 (2 Ω)


• PRE-OUT pass-through from high level SPEAKERS-IN input
• Fully by-passable crossover FILTERS
• Removable panel to conceal and protect controls and wiring
• Solid aluminium heatsink construction
• Fanless convection cooling system
• Power transistors fixed with spiral springs, providing a 50% increase in pressure
• Built in SUBWOOFER volume control module, requires only the connection of optional VCRA controller
• Electronic thermal control system rolls back output power in two levels (-1,5dB / 65°C; -3dB / 75°C)
• Fuse located on the control panel for easy replacement

• Connections:
• Power supply terminal accepts 7 mm diameter (4 AWG) cable
• Speaker terminal accepts 4.5 mm diameter (8 AWG) cables
• Hi Level speaker and remote turn-on terminals equipped with removable
• connectors with screw fastening
