• 4/3/2 Canali
• Protezione Alta Temperatura
• Filtro Subsonico
• Bass EQ Circuit
• Adjustable Crossover (HP/LP)
• MOSFET Power Supply
• DC-DC PWM Power Supply
• Stadio di Pre-Amplificazione Discreto
• Circuito STAR
• Protezione automatica alta corrente
• MultiMode™
• Top Mounted Blue LED Power/Status
• Selettore Ingresso Canali
• Connettori Ingressi RCA in Oro
• Controllo Livello regolabile
• Ingresso Alta Potenza
• Terminali di alimentazione placcati Oro
• Terminali degli speaker placcati in oro
• 4-Layer Glass Epoxy PC Board

Potenza RMS (at 14.4V THD+N, 20Hz-20kHz)

• Per canale a 4 Ohm: 40W x 4 (0.08% THD)
• Per channel into 2 ohms: 75W x 4
• Ponte a 4 Ohm: 180W x 2

Bass Engine® Sound Tuning (Amplificatori)

• Crossover Frequency : 50Hz - 400Hz HP/LP/Off(-12dB/oct)
• Filtro Subsonico (Fixed): 15Hz
• Bass EQ Frequency (Fixed): 50Hz +12dB (Ch-3/4) On/Off

Dimensioni ( Amplificatori)

• Heat Sink (WxHxD) in: 9-9/64¨ x 9-31/64¨ x 2-23/64¨
• Heat Sink (WxHxD) mm: 232mm x 241mm x 60mm
• Foot Print (WxHxD) in: 10-15/16¨ x 9-31/64¨ x 2-23/64¨
• Foot Print (WxHxD) mm: 279mm x 241mm x 60mm

Generale (Amplificatori)

• Power Requirements: 14.4V DC (11V to 16V)
• Fuse Type: 15A x 2
• Risposta in Frequenza: 10Hz - 50kHz (+0,-1dB)
• Signal to Noise (S/N): 100dBA (Reference to Rated Power)
• Input Sensitivity (For Rated Power): 0.2V to 4.0V (1.0 at Center Detent)
• Input Impedance: 10k Ohm
• Speaker Impedance: 4 or 2 ohm Bridged
• Peso: 2.7 Kg.
