Kenwood KAC-9106D

KAC-9106D - Amplificatore Kenwood ad un canale, classe D, potenza RMS: 1 x 500 W, dimensioni: 335 x 56 x 192 mm.

Caratteristiche KAC-9106D

Max Power 2000W
Rated Input Power:
4 ohms 500W x 1
2 ohms 1000W x 1
Signal to Noise Ratio: 100 dB

Specifiche tecniche KAC-9106D

KAC-9106D Amplifier Type Class D
CEA-2006 Primary Ratings Power Output 500Watts RMS x 1 at 4 Ohms and ≤1%THD+N
Signal-to-Noise Ratio 76dBA (Reference: 1Watt into 4Ohms)
Maximum Power Output MAX POWER 2000W
Power Output Rated Power at 14.4V 500Watts RMS x [ch] (4 Ohms, 20-200Hz, ≤1.0% THD)
1000Watts RMS x [ch] (2 Ohms, 100Hz, ≤1.0% THD)
Specifications Signal to Noise Ratio 100dB (Reference: Rated Power into 4Ohms at 14.4V)
Frequency Response 20Hz-200Hz (+0dB, -3dB)
Class D
Input Impedance 10k ohm
Speaker Impedance 4Ω (2Ω to 8Ω allowable)
Con la garanzia del miglior servizio RGsound.it.


Low-Pass Filter
Built in Variable Low-Pass Filter (50Hz-200Hz, -24dB/oct)
Infrasonic Filter Built in Variable Infrasonic Filter (20Hz-50Hz, -24dB/oct)
Bass Boost Built in Bass Boost Control (40Hz, 0dB-+18dB)
RCA Input Sensitivity 0.2[V] - 5.0 [V]

Speaker Level Input Sensitivity
4.0[V] - 12.0 [V]
Terminals Battery & Ground Screw Type Terminal Block (Ni) (M6)
Speaker Output Screw Type Terminal Block (Ni) (M4)
Line In RCA (Ni)
Line Out RCA (Ni)
Speaker Input JST Connector
General Dimensions(WxHxD) 335 [mm] x 56 [mm] x 192 [mm]
Weight　 (kg) 2.8 [kg] 6.2 [lbs]
Operating Voltage 14.4V（11-16V allowable） [V]
Current Consumption 65 [A]
Key Features

CEA-2006 Compliant
Class D
2 Ohms Load Capability
Speaker Level Input
Signal Sensing Turn-on
Terminal Cover
Power MOS-FET Switching Power Supply
Cast Aluminum Heat Sink Design
Line Output Terminals for Extension
