Nominal diameter | 165 mm 6.5 in |
Nominal impedance | 8 Ohm |
Minimum impedance | 7.9 ohm |
Power capacity | 170 W AES |
Program power | 340 W |
Sensitivity | 94 dB 1 W/1 m @ ZN |
Frequency range | 90-8000 Hz |
Recommended enclosure volume | 4 l |
Voice coil diameter | 50.8 mm 2 in |
BL factor | 11.2 N/A |
Moving mass | 0.014 kg |
Winding length | 9 mm |
Air gap height | 7 mm |
Xdamage pp | 20 mm |
Fs | 85 Hz |
Re | 6 ohm |
Qms | 3.7 |
Qes | 0.36 |
Qts | 0.33 |
Vas | 7 l |
Cms | 250 µm / N |
Rms | 2 kg/s |
Efficiency % | 1.2 |
Sd | 0.014 m² |
Xmax | 3 mm |
Vd | 14 cm³ |
Le @1 kHz | 0.2 mH |
Net weight | 1.6 kg 3.5 lb |
Total weight | 1.8 kg 3.96 lb |
Magnet | Neodymium |
