Nominal diameter | 127 mm 5 in |
Nominal impedance | 8 Ohm |
Minimum impedance | 6.7 ohm |
Power capacity | 150 W AES |
Program power | 300 W |
Sensitivity | 92 dB 1 W @ 1 m |
Frequency range | 70-10000 Hz |
Voice coil diameter | 38 mm 1.5 in |
BL factor | 9.9 N/A |
Moving mass | 0.011 Kg |
Winding length | 14 mm |
Air gap height | 6 mm |
Fs | 78 Hz |
Re | 5.3 ohm |
Qms | 10.7 |
Qes | 0.31 |
Qts | 0.3 |
Vas | 4.5 l |
Cms | 355 µm / N |
Rms | 0.5 kg/s |
Efficiency % | 0.68 |
Sd | 0.0095 m² |
Xmax | 5.7 mm |
Vd | 54.15 cm³ |
Le @1 kHz | 0.25 mH |
Depth | 71 mm 2.79 in |
Net weight | 1.24kg 2.73 lb |
Magnet | Neodymium |
