Nominal diameter | 300 mm 12 in |
Nominal impedance | 8 Ohm |
Minimum impedance | 6.5 ohm |
Power capacity | 900 W AES |
Program power | 1800 W |
Sensitivity | 96 dB 1 W @ 1 m @ 2Π |
Frequency range | 30-2500 Hz |
Recommended enclosure volume | 20 / 60 l 0.7 / 2.24 ft³ |
Voice coil diameter | 100 mm 4 in |
BL factor | 25.3 N / A |
Moving mass | 0.100 kg |
Winding length | 21 mm |
Air gap height | 12 mm |
Xdamage pp | 52 mm |
Fs | 47 Hz |
Re | 5.1 ohm |
Qms | 7.89 |
Qes | 0.27 |
Qts | 0.26 |
Vas | 49 l |
Cms | 115 µm / N |
Rms | 3.7 kg / s |
Efficiency % | 1.8 |
Sd | 0.055 m² |
Xmax | 8 mm |
Vd | 440 cm³ |
Le @1 kHz | 2 mH |
Net weight | 5.4 kg 11.88 lb |
Total weight | 6.1 kg 13.42 lb |
Magnet | Neodymium |
