Nominal diameter | 250 mm 10 in |
Nominal impedance | 8 Ohm |
Minimum impedance | 6.1 ohm |
Power capacity | 500 W AES |
Program power | 1000 W |
Sensitivity | 97 dB 1 W @ 1 m @ ZN |
Frequency range | 70-5000 Hz |
Voice coil diameter | 63.5 mm 2.5 in |
BL factor | 18.3 N / A |
Moving mass | 0.044 kg |
Winding length | 19.5 mm |
Air gap height | 9.5 mm |
Xdamage pp | 40 mm |
Fs | 60 Hz |
Re | 5.7 ohm |
Qms | 7.5 |
Qes | 0.29 |
Qts | 0.28 |
Vas | 26 l |
Cms | 154 µm / N |
Rms | 2.3 kg/s |
Efficiency % | 2 |
Sd | 0.035 m² |
Xmax | 8 mm |
Vd | 280 cm³ |
Le @1 kHz | 1mH |
Net weight | 5.7 kg 12.5 lb |
Total weight | 6.1 kg 13.42 lb |
Magnet | Ferrite |
